JIS G3101 SS400/SS490 Carbon structural steel plate

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time:only one week for stock, customized products according to order negotiation.
Loading Port:Shanghai ,Qingdao,Tianjin .
payment terms:By T/T or L/C.
Supply capacity:5000MT/month.
MOQ: According to order negotiation.

Inquire Now Chat Now

PRODUCT DESCRIPTION

JIS G3101 SS400 Carbon structural steel plate Chemical Composition

Chemical composition % max
Grade	C	Mn	P	S
SS400	~	~	0.05	0.05

JIS G3101 SS400 Carbon structural steel plate Mechanical Property

SS400 Mechanical properties min
Yield strength (N/MM2)				Tensile strength (N/MM2)	Elongation %
≤16	>16≤40	>40≤100	>100	400-510	17
245	235	215	205

JIS G3101 SS400 Carbon structural steel plate JIS G3101 SS400 Carbon steel plate

Application

JIS G3101 SS400 Steel Plate are used in Construction of Bridge

JIS G3101 SS400 Carbon structural steel plate JIS G3101 SS400 Carbon structural steel plate Other Name

JIS G3101 SS400 Carbon Structural Steel Plate,JIS G3101 SS400 High Strength Structural Steel Plate,JIS G3101 SS400 Carbon Steel plate,JIS G3101 SS400 Structural Steel Plate.

JIS G3101 SS400 Carbon structural steel plate Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
